CINEMA 70s features a highly compact slimline design, making theaters possible in spaces where equipment cannot occupy large amounts of space. CINEMA 70s comes replete with the latest immersive audio formats and an all-new HD graphical user interface makes setup from your sofa intuitive.
Slimline Design
7.2 Channels
50 Watts per Channel
6 HDMI Inputs plus eARC
8K & Dolby Atmos
HEOS Built-in
The Marantz Sound Master meticulously tuned CINEMA 70s for amazing performance with careful parts selection to create the Most Musical Sound in your home. Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series are the foundation of the world’s most demanding home theaters. It has won me over in how versatile it can be.
Details & Specifications
Power Amplifier
Number of Powered Channels7
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive)50 W
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / PreoutYes / Yes
Zone HDMI Output from HDMI SourceNo
Control ConnectivityIP Control / Web Control / App Control
IR Flasher InYes
Marantz Remote BusYes
DC Trigger Output1
HDMI DiagnosticsYes
Others
Front Displayport hole OLED
GUI Languages3
Setup AssistantYes
Smart Select on RemoteYes
Firmware Update by Network / USBYes / Yes
ECO ModeYes
Auto Power offYes
Sleep TimerYes
General
Availabe coloursBlack
Metal Front PanelNo
System Remote ControlRC050SR
Power Consumption in W250
Power Consumption No-Sound (ECO on/off) in W30 / 40
Standby Consumption in W0.2
CEC Standby Consumption in W0.5
Network Standby Consumption in WLess than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
Antenna:Vertical :(W x D x H) in mm
W/o Antenna:(W x D x H) in mm442 x 384 x 109
( 442 x 384 x 178 )
【 442 x 372 x 109 】
Weight in kg8.7
What’s in the boxMain unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord
