Description

Portable PA
Max. Power Output 100 Watts
Amplifier Class AB
Sensitivity Typical: 98 dB | Maximum: 111 dB
T.H.D. < 1% Frequency Response 50 Hz ~ 18 kHz Speaker 8 ” full-range Audio Inputs Wired: XLR × 1, Ø 6.3 mm (1/4 “) × 1 Wireless: Up to 2 wireless microphones Audio Player: CDM-2 Line-In: Unbalanced Ø 6.3 mm (1/4 “) jack Audio Output Unbalanced Line Ø 6.3 mm (1/4 “) jack Extension Speaker Ø 6.3 mm (1/4 “) Phone jack Volume Master and other individual controls Controls Tone control Storage 2 handheld or bodypack transmitters Installation Speaker stand, flat surface or retractable handle & wheels Power Supply AC: Built-in 100 ~ 240 V AC switching power supply (Max. Power Consumption: 120 W) DC & Battery: 24 ~ 32 V DC,12 V / 4.5 AH rechargeable gel cell battery (MB-70 × 2) or optional MB-80 × 2 Charge Time 8 hours (automatic charging management) Standby Time > 8 hours
Battery Indicator Single LED indicator
Color Black
Dimensions (W × H × D) 310 × 445 × 240 mm / 12.2 × 17.5 × 9.4 ”
Weight Approx. 14.8 kg / 32.5 lbs, batteries included
Wireless System (optional)
Receiver MRM-70B︱MRM-70W︱MRM-80︱MRM-24︱MRM-58 Scan & ACT sync
Max. Receiver Up to 2
Frequency Range
MRM-70B︱MRM-70W︱MRM-80: UHF 480 ~ 934 MHz (country dependent)
MRM-24: 2.4 GHz
MRM-58: 5.8 GHz

Preset Channels & Bandwidth See Accessories – Receiver Modules
Transmitters See Accessories – Receiver Modules
Microphones MM-107︱MM-39︱MM-59 Wired Dynamic Microphone
Installation Plug-in Module
Antenna Built-in active dual antennas
Audio Player (optional)
Model CDM-2
Installation Plug-in Module
Note Refer to actual product in the event of product description discrepancy.
