Consistent and precise power wherever and however you need it.If you’re impressed by elegantly restrained industrial design, the MM7025 is guaranteed to make a lasting – and very positive – impression.As befits a Marantz amplifier, the high-capacity power supply begins with an oversized EI-core transformer feeding carefully chosen capacitors capable of storing 30,000 µF of energy. This combination instantaneously delivers peak power to all amplifier stages for distortion-free reproduction of the most complex sources.
Featuring an industrial design, high-capacity power supply, and assured system compatibility, MM7025 delivers an expansive soundstage and superior sound clarity
Classic Design
2 Channels
140 Watts per Channel
Class A/B Amplifier
Details & Specifications
Features
Channels2
Current Feedback TopologyYes
Phono EQ: Standard / Current Feedback / Constant Current FeedbackNo / No / No
HDAM versionNo
Power Transformer: Toroidal / ElNo / Yes
High Grade Audio ComponentsYes
Customised ComponentsYes
Symmetric PCB LayoutNo
Aluminium extrusion heat sinkYes
Copper Plated ChassisYes
Tri Tone Control (Bass / Mid / Treble)No
Balance / Bass / Treble / LoudnessNo
Others
Linear Drive Power SupplyYes
CCNENo
Liniear volume controlNo
BTL PossibilityNo
BI-AMP and Multichannel optionNo
Choke inputNo
Shottky diodesNo
Input buffer amp (all inputs / CD only)Yes / No
Separate Solid Heat SinksNo
System block shielding: Copper / metal / noneNo / No / No
Double Layer Bottom PlateNo
Low noise LCD displayYes
Low noise LED displayNo
Power Meter : Analog / DigitalNo / Yes
Source DirectNo
Power Amp directYes
Standby ModeYes
5mm aluminium top plateNo
Inputs Outputs
Audio InputsNo
Phono Input: MM / MCNo
Audio OutputsNo
Balanced In / Out2 / No
Pre-out / Main-inNo / 2
Power Amp Direct INNo
Gold Plated CinchNo
Speaker A / BNo
Speaker Terminal: Screw / Marantz / WBTYes / No / No
Number of terminals2
D-BusYes
Floating Control Bus (3.5 mm mono jack x 2)No
Remote Power Control Trigger – In OutYes
Flasher In / IR Receiver InYes / No
Headphone OutNo
iPod input (direct / docking station)No / No
Specifications
Power Output (8 / 4 Ohm RMS)140 W / 170 W (6)
Power Output (8 / 4 Ohm DIN)No
Power Output (8 / 4 Ohm IHF)No
Bridged Power Output (8 Ohm RMS)No
Frequency response8 Hz-100 kHz (+-3 dB)
Total Harmonic Distortion0.03% (20 Hz – 20 kHz)
Damping Factor100
Input Sensitivity: MMNo
Input Sensitivity: MCNo
Signal to Noise Ratio: MM/MCNo
Input Sensitivity: High level1.2 V / 22 K
Input Sensitivity: Balanced High level2.4 V / 30 K
Signal to Noise Ratio: High level105 dB
General
Available Colors: Gold / Silver / Black / Silver-GoldNo / No / Yes / No
Metal Front PanelYes
Power Consumption in W220
Standby Consumption in W0.4
Auto Power offYes
Detachable Power CableYes
Remote ControlNo
System Remote FunctionNo
Maximum Dimensions (W x D x H) in mm440 x 126 x 352
