TEAC UD-301 D/A Converter with USB Streaming
A new standard in high-resolution audio, delivering high performance audio from a desktop component
- Description
Description
| DAC Section | |
| D/A Converter | BurrBrown PCM1795×2 |
| Up-conversion | 192kHz (user defeatable) |
| Digital audio inputs | |
| USB | |
| Connector | USB Type B (USB2.0) |
| Transmission mode | Asynchronous mode |
| DSD data sampling frequency | 2.8M/5.6M Hz |
| PCM data sampling frequency | 32k/44.1k/48k/88.2k/96k/176.4k/192k Hz |
| Bit rates | 16/24/32 bit |
| COAXIAL | |
| Connector | RCA jack |
| PCM data sampling frequency | 32k/44.1k/48k/88.2k/96k/176.4k/192k Hz |
| Bit rates | 16/24 bit |
| Input level | 0.5Vp-p |
| Input impedance | 75 ohms |
| OPTICAL | |
| Connector | Optical digital connector |
| PCM data sampling frequency | 32k/44.1k/48k/88.2k/96k Hz |
| Bit rates | 16/24 bit |
| Input level | -24 to -14.5dBm peak |
| Analog audio outputs | |
| XLR | |
| Connector | XLR-3-32 |
| Maximum output level | +14dBu(1kHz, full-scale, 10k ohms with load, 0dB when set) |
| Output impedance | 200 ohms |
| RCA | |
| Connector | RCA jack |
| Maximum output level | 2.0Vrms(1kHz, full-scale, 10k ohms when loaded) |
| Output impedance | 100 ohms |
| Headphone output | |
| Connector | 6.3mm(1/4″) stereo phone jack |
| Maximum output | 100mW + +100mW (32 ohms with load, distortion rate 0.1%) |
| Compatibility impedance | 8 ohms to 600 ohms |
| Power supply | |
| USA/Canada | AC 120V, 60Hz |
| Europe | AC 230V, 50Hz |
| Power consumption | 10W |
| Dimensions (including protrusions) | 215(W)×61(H)×238(D)mm 8.5″(W)×2.4″(H)×9.4″(D) |
| Weight | 2.0kg 4.4 lbs |
| Accessories | Power cord, Instruction Guide (including Warranty) |
