Description

Overview

ATC SM75-150 S Soft Dome Mid driver
Latest 375mm SL Spec Bass driver
Massive ATC motor assembly
Wide, even dispersion for pin-point imaging
350 watt class AB tri-amp pack
Active filters and overload protection
6 year warranty
Also available in passive version
Featured veneer: Cherry

Description
Drivers: HF 25mm Neodymium, Mid 75mm ATC Soft Dome, LF 375mm SL
Frequency Response (±2dB): 60Hz–17kHz
Frequency Response (±6dB): 25Hz–22kHz
Matched Response: ±0.5dB
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Max SPL: 117dB
Crossover Frequencies: 380Hz & 3.5kHz
Connectors: Male XLR
Filters: All active
Amplifier Output: 200w LF, 100w Mid, 50w HF
Cabinet Dimensions (HxWxD): 1104x495x635mm
Weight: 77kg
