Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series are the foundation of the world’s most demanding home theaters.A modern expression of timeless design principles, AMP 10 features the iconic Marantz porthole level meter, premium materials, and subtle sidelights that illuminate the front panel.We developed custom Class D amplifiers and refined our own HDAM-SA2 technology to create the most incredible theatrical experience possible in your home.
Engineered with best-in-class technologies, AMP 10 cleverly combines very high-power output and high channel count to create a master reference-level amplifier for ultimate home theater performance.
Crafted in Shirakawa, Japan
16 Channels
200 Watts per Channel
Custom HDAM
Custom Switching Amplifiers
Selectable Output Modes
Details & Specifications
Multi-Room CI
IP Control / RS232 Control / Web Control / App ControlNo / Yes / No / No
IR Flasher InYes
Marantz Remote BusYes
DC Trigger Input/ Output1 / 1
Others
Front DisplayLevel Meter
Firmware Update by Network / USB / RS232CNo / No / No
Auto Power offYes
Inputs Outputs
Main Amplifier inBalanced & Unbalanced: 16ch (Exclusive use by a selector switch.)
Speaker TerminalSPKT-1+
Number of Speaker Terminals16
Bi-Amp Drive /BTL DriveYes / Yes
Level MeterYes
ChasissCopper Plated
Specifications
Number of poweramps16
Power Output (8 ohm, 1 kHz, 0.05% 2ch Drive) Normal / BTL200W / 400W
Power Output (4 ohm, 1 kHz, 0.7% 2ch Drive) Normal400W
Power Output (8 ohm, 1 kHz, 0.7% 5ch Drive) Normal200W
70% Guarantee(Normal/Bi-Amp/BTL)Yes
100% Guarantee(Normal/Bi-Amp)Yes
General
Metal Front PanelYes
Pre-Programmed / Learnable / LCD DisplayNo / No / No
Power Consumption in W500
Power Consumption No-Sound (ECO on/off) in WNo / 140W
Standby Consumption in W0.2
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
Antenna:Vertical :(W x D x H) in mm
W/o Antenna:(W x D x H) in mmNo x No x No
( No x No x No )
【 17.4 x 19.2 x 7.4 】
Weight in lbs.43.7
What’s in the boxMain unit, quick start guide, AC cord,
Amp control cable, Remote control cable,
SP terminal wrench
