Bowers & Wilkins DB3D – High-performance 8-in subwoofer

Description

High--DB3D Satin White Grille Off Rear Beauty.jpg
Despite its compact dimensions, DB3D delivers astonishingly powerful, controlled bass thanks to its twin 8-in Aerofoil™ drivers, amplifier and digital signal processing.
High--DB3D and 805 D3 Satin White Cinema.jpg

Power packed

DB3D’s tight, powerful, dramatic bass and compact size make it the perfect match for the 804 D4 and 805 D4 speakers.

DB3D - More bass, less space

More bass, less space

Compact model packs a mighty punch. Controllable, dramatic bass from a subwoofer so small it fits almost anywhere: DB3D is a space-saving high-performance design.

DB3D - Nimble and powerful

Nimble and powerful

Solid, dramatic bass is delivered through the rigidity and lightness of the uniquely-shaped, variable thickness Aerofoil™ cone.

DB3D - A question of balance

A question of balance

The back-to-back (opposed) drivers cancel out cabinet resonances, ensuring all that power is used to create room-shaking bass, not wasted vibrations.

DB3D - The digital advantage

The digital advantage

Digital amplification is cool-running and energy efficient, even when working hard, while Dynamic EQ and Room EQ ensure a precise sound for music and movies.

DB3D - Take control

Take control

By placing control in the palm of your hand, our subwoofer app not only makes our DB Series subwoofers a snap to set up, it also helps maximize your sound quality.

High--DB1D, DB2D and DB3D Beauty.jpg

Description
DB Series subwoofer

Technical features
1000w Class D Hypex amplifier
2 x 200mm (8in) Aerofoil™ cone drive units in a balanced configuration
Digital preamplifier with Dynamic EQ
App-based set-up and BT-LE control

Drive units
2 x 200mm (8in) Aerofoil™ cone drive units in a balanced configuration

Frequency range (-6dB)
8.5Hz – 500Hz

Frequency response -3dB (centered on level at 100Hz)
10Hz – 350 Hz

Max power output
1000W

Inputs
2 x XLR
2 x RCA
2 x 3.5mm 12V trigger
RS-232 – 9-pin D connector

Dimensions
Height: 360mm (14.1in)
Width: 320mm (12.6in)
Depth: 300mm (11.8in)

Net weight
25kg

Cabinet finishes
Gloss Black
Satin White
Rosenut

Grille finishes
Black
Grey
