Dali Opticon on Wall
- Description
- Specification
Description
Dali Opticon LCR Wall Mounted Speaker
Color :- Black , Walnut ,White
The OPTICON LCR – a wall-mount model that’s combines the best of all technologies into a slim wall mounted cabinet that works wonders with sound. Second to none in terms of flexibility and performance. With airy highs, a detailed mid-range and a surprising bass, this on-wall speaker delivers a larger than life performance.
Capable of operating as either an independent 2.0 system or as the centre channel in a larger set-up, the rotatable OPTICON LCR fires out its audacious audio via a 6½ inch low-loss Wood Fibre Woofer.
Added to this is our rotatable Hybrid Tweeter module and, finishing the ear-delighting effect, an advanced bass port configuration built into the back panel which uses the wall on which it is mounted to extend its acoustic properties. The result is truly astounding bass response despite a compact cabinet, without the need for an additional subwoofer in your sound set-up.
Whether you want one loudspeaker on your wall to handle all your audio needs or a centre loudspeaker to add that something extra to your surround system, the OPTICON LCR is your sound solution.
Legacy
The OPTICON LCR features the same low-loss Wood Fibre Woofer found in our flagship EPICON series, alongside our unique SMC (Soft Magnetic Compound) magnet motor system and a reworked version of our Hybrid Tweeter module also found in the RUBICON, all of which works together along with a individual bass reflex port for the woofer to produce audio exactly as the recording artist originally envisioned it.
HAND-ASSEMBLED
The mounting of the drivers and the final tests and approvals on each and every speaker is also handled directly at our own assembly lines in our Danish factory.
DALI DRIVERS
All elements of the DALI drivers are designed, produced and manufactured in-house in DALI.
DALI MDF CABINETS
Keeping the manufacturing of the OPTICON series firmly in the hands of DALI we utilize our large and efficient woodworking facility in Denmark to handle everything from cutting out the Medium Density Fibre board (MDF) cabinet to applying the vinyl.
SMC-TECHNOLOGY
In the OPTICON woofer magnet motor system the pole piece is purely constructed of SMC. SMC’s unique ability to deliver a high magnetic conductivity and a very low electrical conductivity delivers all the wanted qualities of a really good speaker magnet without the traditional downsides.
DALI OPTICON LCR SPECS
Product series | OPTICON |
---|---|
Frequency Range (+/-3 dB) [Hz] | 72 – 32,000 |
Sensitivity (2,83 V/1 m) [dB] | 90.5 |
Nominal Impedance [ohms] | 4 |
Maximum SPL [dB] | 109 |
Recommended Amplifier Power [W] | 40 – 300 |
Crossover Frequency [Hz] | 2,200 / 14,000 |
Crossover Principle | 2 + ½-way |
Hybrid tweeter module, Super high freq. driver, Quantity | 1 x 17 x 45 mm |
Hybrid tweeter module, Super high freq. driver, Diaphragm type | Ribbon |
Hybrid tweeter module, High frequency driver, Quantity | 1 x 28 mm |
Hybrid tweeter module, High frequency driver Diaphragm type | Soft Textile Dome |
Midrange driver, Quantity | 1 x 6 1/2″ |
Midrange driver, Diaphragm type | Wood Fibre Cone |
Enclosure type | Bass Reflex |
Bass Reflex Tuning Frequency [Hz] | 45.5 |
Connection Input | Single Wire |
Magnetic Shielding | No |
Recommended Placement | On-Wall Centre / Soundbar |
Recommended Distance From Wall [cm] | 0 – 10 |
Dimensions With Base (HxWxD) [mm] | 482 x 285 x 127 |
Weight [kg] | 8.3 |
