JBL CONTROL 30 Three-Way High Output Indoor / Outdoor Monitor Speaker

  • Features

    • Extended bandwidth, extremely smooth frequency response.
    • Fully outdoor-capable design, featuring WeatherMax™.
    • 120° x 110° HF coverage.
    • 150 W transformer for 70 V or 100 V lines, with 8 thru.
    • SonicGuard® overload protection.
    • 250 mm (10 in) fiberglass / Kevlar® cone LF woofer, with neodymium magnet coaxial 125 mm (5 in) anodized aluminum cone MR, and 25 mm (1 in) titanium diaphragm compression driver.
    • Includes InvisiBall® mounting hardware, plus ten 6 mm attachment points for suspension and optional U-bracket.
    • Sealed input panel cover and screw-down input terminals.

Description

Three-Way High Output Indoor / Outdoor Monitor Speaker

The Control 30 utilizes high power components, computer optimized horn and coaxial component design, patent-pending cabinet manufacturing techniques, and a complex network to achieve smooth high fidelity performance, extended bandwidth and well-controlled, defined coverage from a compact loudspeaker.

Features

  • Extended bandwidth, extremely smooth frequency response.
  • Fully outdoor-capable design, featuring WeatherMax™.
  • 120° x 110° HF coverage.
  • 150 W transformer for 70 V or 100 V lines, with 8 thru.
  • SonicGuard® overload protection.
  • 250 mm (10 in) fiberglass / Kevlar® cone LF woofer, with neodymium magnet coaxial 125 mm (5 in) anodized aluminum cone MR, and 25 mm (1 in) titanium diaphragm compression driver.
  • Includes InvisiBall® mounting hardware, plus ten 6 mm attachment points for suspension and optional U-bracket.
  • Sealed input panel cover and screw-down input terminals.





Frequency Range38 Hz – 17 kHz (-10 dB)
Power Capacity500 W Continuous Program Power; 250 W Continuous Pink Noise
Transformer Taps70 V: 150 W, 75 W, 38 W, 19 W 100 V: 150 W, 75 W, 38 W Thru Position: 4 ohms nominal
Frequency Response40 Hz – 16 kHz ( ± 3 dB)
Maximum SPL (1m)Short-Term: 123 dB; Long-Term: 117 dB
Sensitivity93 dB, 1W @ 1m (3.3 ft)
Coverage Angle120° H x 110° V
Directivity Factor (Q)5.2 dB, averaged 500 Hz to 10 kHz
Directivity Index (DI)7.1 dB, averaged 500 Hz to 10 kHz
Impedance4 ohms
Crossover Network3rd order Low Pass LF, 2nd order High Pass/3rd order Low Pass MF, 3rd order High Pass, HF, plus conjugate shaping circuitry.
DriversLF: 250 mm (10 in) fiberglass/Kevlar® cone with pure butyl rubber surround, 50 mm (2 in) voice coil on fiberglass former, neodymium magnet
MF: 125 mm (5 in) anodized aluminum cone with EPDM rubber (Terpolymer of Ethylene and Propylene) surround, 25 mm (1 in) voice coil on fiberglass former
HF: 25 mm (1 in) compression driver, pure titanium diaphragm with patented JBL diamond surround
EnclosureHigh Impact PolyStyrene (HIPS) with 10% glass fill plus patent pending internal 5 mm foamed polyurethane secondary mold
GrilleThermoset composite coated steel, WeatherMax multi-layer foam
Overload ProtectionSonicGuard full range power limiting to protect network and transducers.
Outdoor CapabilityIEC 529 IP-X5 rating. Exceeds Mil Spec 810 for humidity, salt spray, temperature & UV. Passes Mil-Std-202F for salt spray.
Input ConnectorsScrew-down terminal strip, zinc plated copper base, nickel plated metal screws/washers. Accepts up to 9 mm outside 4 mm inside open
Safety AgencyTransformer is listed per UL1876
ColorsBlack or white (-WH)
Dimensions (H x W x D)593 x 372 x 345 mm (23.3 x 14.6 x 13.5 in.)
Net Weight (each)18.9 kg (42 lb)
Shipping Weight (ea)20.3 kg (45 lb)
Included Accessories1 pc MTC-PC2 input panel cover, InvisiBall mounting base, 6 mm x 305 mm InvisiBall Hex wrench.
Optional AccessoriesMTC-30CM (-WH) to install speaker down from the ceiling. MTC-30UB (-WH) U-Bracket
Mounting HardwareInvisiBall™ aimable wall-mounting system included. Optional U-bracket.
