Focal 100 ICW6 in-ceiling & in wall 2 way Coaxial Loudspeaker

Key points
• In-wall/in-ceiling coaxial 2-way loudspeaker
• Quick, easy, no-tool product assembly
• Speaker driver developed and manufactured in France by Focal
• Delivered with square and circular grilles ready for painting
• Black and white felt ready to stick
• Off-axis response control (tweeter position and gain adjustment)


The 100 ICW6 loudspeaker which is dedicated to home audio can be highlighted for its acoustic performances and compact design. This product is aimed at small to medium sized rooms and for three types of use: distributed systems (hallways, living rooms…),

stereo systems (bedrooms, kitchens…) and Home Cinema systems (in dedicated rooms or living rooms). The product is suitable for every room in the house, even in humid environments such as bathrooms. It can be used in-wall or in-ceiling.

This coaxial loudspeaker has a new aluminum inverted dome adjustable tweeter, more compact, improving sound dispersion. It is also equipped with a new Polyglass cone (61/2” – 16.5 cm). A new crossover improves the off-axis listening and avoids the “shower effect”.

This product can be installed everywhere thanks to a compact design with the speaker driver’s basket and chassis being redesigned as a single piece and also to square and circular magnetic front grilles, frameless. The 100 Series brings an unexpected musicality to your home with ease. Let yourself be surprised by the technology behind this product, an efficient design and ideal features for an easy use at this price.







Technical specifications

Type of speaker                                    2-Way in-wall/in-ceiling
Speaker drivers                                    6 1/2″ (16.5cm) ‘W’ Midrange/Bass
1″ (25mm) Pure Beryllium inverted dome tweeter
Sensitivity (2.83V/3 feet – 1m)          89dB
Bandwidth (+/-3dB)                           55Hz – 40kHz
Low-frequency cut-off (-6dB)           45Hz
Nominal impedance                             8 Ω
Minimal impedance                             4.9 Ω
Recommended amp power                 25 – 150W
Size (Ø x depth)                                     9 5/8 x 4 1/8″ (244 x 105mm)
Mounting diameter (Ø)                       8 1/2″ (216mm)
Mounting depth                                    4″ (100mm)
Net weight (with grille)                       5.29lbs (2.4kg)
Box size (length x depth x height)     12 1/4 x 12 1/4 x 10 5/8″ (310 x 310 x 270mm)
Total weight (with packaging)           8.60lbs (3.9kg)
