Description

Overview

Full SL Spec Bass driver with 75mm integral soft dome
9kg optimised motor assembly
In-house, hand wound precision flat wire coil
Wide, even dispersion for pin-point imaging
250watt Class AB bi-amp pack (active version)
Active filters and overload protection (active version)
6 year warranty
Featured veneer: Oak

Active

Drivers: HF 25mm Neodymium, Mid/LF 150mm
Frequency Response (±2dB): 80Hz–17kHz
Frequency Response (±6dB): 60Hz–22kHz
Matched Response: ±0.5dB
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Max SPL: 108dB
Crossover Frequency: 2.8kHz
Connectors: Male XLR
Filters: Active & Passive – 2nd Order Linkwitz-Riley
Amplifier Output: 200w LF, 50w HF
Cabinet Dimensions (HxWxD): 1023x239x365mm
Weight: 40kg
