PERLISTEN Subwoofer D212s

Description

MODEL D212s Subwoofer:

Dynamic, Accurate, Solid. The audiophile’s choice.

Where sound quality and Transients free of overhang are paramount. Simply no better expression of bass performance then our push-pull subs. Ground up drivers developed by our team of engineers.

Carbon fiber composite diaphragms, multiple aluminum shorting rings, massive magnets, multi-layer Nomex spiders and lightweight aluminum voice coil wire are the key ingredients – Proprietary nonlinear modeling techniques allow us to simulate all these components and then optimize for real world driver performance – free air and in box. Further refinement is done with the aid of Klippel laser measurements to dial things in.

To take performance to another level, the push-pull drivers reduce even order harmonics distortion by an additional 10-12dB. Powerd by our 3.0kW amplifier, all functions and safeties are controlled by a 48-bit data bath DSP and 32-bit ARM M4 Cortex processor, able to react in microseconds, powerful enough to slam.

All D-Series subs share our 2.4” LCD touchscreen display and ability to control advance settings using our App. Ceritfied by THX Dominus, The D-Series subs are the world’s first. A testament to the level of design and performance achieved.

AlignmentPush-Pull, acoustic suspension
Amplifer3.0kW rms short term
Display Interface2.4″ LCD color touchscreen
AppiOS and Android
Processor32-bit ARM Cortex M4, double precision floating point math
DSP EngineTi DSP 48-bit data paths
Driver compliment(2)300mm, Carbon fiber diaprhragm
+/-30mm linear excursion
Frequency Response
THX EQ
Boost (Large Room) EQ
Cut (Small Room) EQ
20-231Hz (-6dB) / 16-245Hz (-10dB)
15-231Hz (-6dB) / 13.5-245Hz (-10dB)
24-231Hz (-6dB) / 18-245Hz (-10dB)
Inputs(2) Balanced XLR
(2) Unbalanced RCA
Outputs(2) Balanced XLR unbuffered
(2) Unbalanced RCA unbuffered
Parametric EQ10-Band PEQ with 3 user presets
Low Pass filterBypass, 30-160Hz, slope 6,12,18,24dB/oct
PhaseVariable 0-270°
PolarityNormal / inverted
Configurable Auto turn-on and 12v TriggerXLR 1, XLR 1+2, RCA 1, RCA 1+2
Dimensions (HxWxD)668 x 420 x 550mm
26.3 x 16.5 x 21.6″
Weight68.0 kg (149.6 lbs.)
CertificationTHX Dominus
Available finishesPiano black
