BMB WB-5000S UHF Wireless Microphone System

Description

Highlight of BMB WB-5000S UHF Wireless Microphone System

  • By adopting a high-performance microchip and suppressing distortion, we realized a unique wireless quality microphone unique to BMB.
  • It uses high-quality liquid crystal, it is easy to see in any installation situation.
  • When the microphone dropped, The microphone will become mute.
  • It will not occur the Large volume Noise, when falling more than 20 cm.
  • New function that microphone automatically connect to receiver by shaking microphone. (WB-5000 / WM-500

SYSTEM

Type Unidirectional dynamics UHF Wireless microphone system
Frequency Range 640Hz – 690Hz
Channel 200CH
Frequency Response 100Hz – 10Hz
Effective Distance 50m
Frequency Interval 250KHz
Frequency Width 50MHz
Frequency Oscillation Mode PLL Module locked loop design
Radio Frequency Sensitivity -90dBm
Total Harmonic Distortion < 5%
Dynamic Range >70dB

RECEIVER

SNR ≥50db
Frequency Stability ±5KHz
Signal Pick Up CPU controlled selection & pilot identification
Mute Mute & Lock Loop Circuit
Disply LCD
DC Input 12V DC ≥1000mA
Output Impedance 600Ω
Output 2 XLR Balance Socket + Unbalance TRS 6.3mm Socket
Dimensions (mm) 420(W) x 44(H) x 160(D)

MICROPHONE

Frequency Oscillation Mode PLL module locked loop design
Transmission Method CPU controlled carried wave & pilot identification
RF Stability ±5KHz
Display LCD+color backlit
Capsule Dynamic
Power Level Hight & Low
Power Supply 2 Pcs AA Battery
Weight 0.55KG
Dimensions (mm) 50(Φ) x 247(L)
